WENS860 60 MHz Oscilloscope

0 reviews  (0/5 ) 0 reviews  •  Write a review
Product Code: 81743
Availability: In Stock Views: 740
DeliverySame Day Delivery
$1,045.79
Qty: Add to Cart

Shipping Options to United States

Select Country:
* Region / State:

WENS860 60 MHz Oscilloscope info

SILOSCOPE PROPERTIES
BAND WIDTH 60MHz BAND WIDTH
SAMPLING RATIO 200MS / s REAL SAMPLING
LOGIN
Input Channels 300Vrms, CAT II
Input Coupling 2 Channel
Input Impedance DC, AC, GND
Probe Reduction Factor 1MΩ ± 1%, 20pF ± 3pF
Maximum Voltage Between Signal and Common in BNC 1X, 10X, 100X, 1000X
VERTICAL
Analog Bandwidth 20 MHz
Analog Bandwidth Limiter 20 MHz
Vertical Resolution 8-Bit
VOLTS / DIV Stage 5 mV / div ~ 100 V / div (1, 2, 5 Step)
Offset Stage ± 5 div
Vertical Accuracy ± 3%
Rise Time at BNC 2.3 ns
HORIZONTAL
SEC / DIV Stage 10 ns / div ~ 50 s / div
Time Base Accuracy ± 0.01%
Position Stage First-trigger: 20div max. Last-trigger: 1000div
TRIGGING
Trigger Source CH1, CH2, AC Line, EXT
Trigger Coupling DC, AC, HF REJ, LF REJ, Noise REJ
Trigger Modes Edge, Pulse Width, Delay, Pattern, TV
External Trigger Stage ± 15V
Trigger Accuracy Approx. 0.2 div
GAIN
Real Time Sampling Rate 200MS / s Single channel 100MS / s Per channel
Waveform Interpolation Dot, Linear, Sine, Pulse
Record Length 125 kbytes / channel
Gain Modu Sample, Peak Detect, Envelope, Average
Peak (Peak) Finding 10 ns
MEASUREMENT
Cursor Voltage differential (DV) / Time difference (DT)
Automatic Measurement There are two cursors, the opposite of DT
Frequency, Period, Mean, Pk-Pk, Cycle RMS,
Min, Max, High, Low, Duty, Delay, Rise Time,
Fall Time, Positive Overshoot, Negative Overshoot
FUNCTION
Save / Recall 10 Waveforms, 10 Settings
Zoom Direct Time / Volt conversion
XY Mode X Axis Channel Input - Y Axis Channel Input
