Each functional module is connected to VCC, GND and output ports and corresponding prototypes on the Sensor Shield with a straight 2.54mm twin female cable.
Locked cables make connections easier, safer and more professional looking.
Just plug and play.
Working Voltage: 5VDC.
Input Voltage (recommended): 7-12VDC.
Input Voltage (limits): 6-20VDC.
Locked Analog Port: VCC / GND 6 Convenient, solid connection for analog inputs.
Digital IO port 13 ports ready for digital modules or servos.
Analog IO Port: 2.54 gridKek pin header connections.
Locked Port: Selectable between I2C and UART.
